Application: the hammer crusher can crush medium-hard and crispy materials, such as limestone and coal with compression resistance less than 150MPa. It is mainly used in the cement plant, mineral, coal, electrical and chemical industries.

Main technical parameters for hammer crusher

Type

Specifications

Feeding
size(mm)

Discharging
size(mm)

Capacity (m3/h)

Motor

Total
weight
(t)

Dimensions
(L*W*H)(mm)

Electr-
icity

Power
(kw)

Hammer
crusher

PCΦ400*300

<=200

<=25

5-10

4

11

0.8

900*670*860

PCΦ600*400

<=250

<=30

10-22

4

22

1.5

1200*1050*1200

PCΦ800*600

<=250

<=25

18-40

4

55

3.2

1310*1180*1310

PCΦ1000*800

<=350

<=35

25-50

4

75

4.3

1600*1390*1575

PCΦ1000*1000

<=300

<=35

30-55

6

132

8

1800*1590*1775

PCΦ1250*1250

<=350

<=35

35-65

6

180

14

2060*1600*1890

PCΦ1400*1400

<=350

<=35

50-100

6

280

32

2365*1870*2220

PCΦ1600*1600

<=350

<=35

100-150

8

480

37.5

3050*2850*2800
